- Secondary development unlocked Unitree's unitree_sdk2 in C++ and Python on DDS, compatible with ROS 2 Foxy and Humble, gives high-level control of locomotion, arm actions, audio and video and joint-level control in debug mode.
- 40 TOPS Jetson Orin backpack The computing backpack carries an NVIDIA Jetson Orin module rated at 40 TOPS as the development computer for your own programs.
- From simulation to the robot URDF, STEP and MuJoCo models of the R1 let you develop and test in simulation before running the same algorithms on the robot.
- Perception and navigation The head camera streams RGB and depth to the backpack, and Unitree's SLAM and navigation service runs indoors with the optional LiDAR.
- Hand-ready The dexterous-hand expansion module on the backpack provides power, signal and camera connections for hands.
- The full R1 body Twenty-six joints, about 1.23 m and 29 kg, a binocular depth camera, voice and image AI and a 6000 mAh quick-release battery for about 1 hour.
- 12-month manufacturer warranty Every R1 EDU carries Unitree's 12-month warranty, against 8 months on the R1 Basic.
Description
The Unitree R1 EDU Standard (U1) is the entry configuration of the R1 EDU, Unitree's developer edition of the R1 humanoid. It keeps the 1.23 m, 29 kg body with 26 joint motors, adds secondary development and carries a computing backpack with an NVIDIA Jetson Orin module rated at 40 TOPS. It has no dexterous hands.
Development runs on the backpack's development computing unit. Unitree's unitree_sdk2 in C++ and Python works over DDS and is compatible with ROS 2 Foxy and Humble, with high-level interfaces for locomotion, arm actions, audio and video and joint-level control in debug mode. URDF, STEP and MuJoCo models of the R1 let work move from simulation to the robot, and Unitree's SLAM and navigation service runs indoors with the optional LiDAR.
The backpack also carries the dexterous-hand expansion module, with power, signal and camera connections. For teaching labs and research groups starting with locomotion, perception and voice work, the EDU Standard is the R1 EDU at its lowest computing level. Unitree publishes one R1 EDU with hands and an Orin module as options; U1 to U6 name the six configurations Robotix Market offers.
The R1 EDU Smart (U2) raises the backpack to 100 TOPS. Pro A and Pro B (Unitree Dex3-1) and Pro C and Pro D (BrainCo Revo 2) add two dexterous hands on the 100 TOPS backpack. The R1 Basic is the same robot without secondary development.
Key Capabilities
- Secondary development: unitree_sdk2 (C++, Python) on DDS, ROS 2 compatible, high-level and joint-level control.
- Computing backpack: NVIDIA Jetson Orin, 40 TOPS, as the development computer.
- Simulation: URDF, STEP and MuJoCo models of the R1.
- Navigation: Unitree's SLAM and navigation service with the optional LiDAR, indoors.
- Hand-ready: Dexterous-hand expansion module with power, signal and camera connections; no hands fitted.
- Body: 1.23 m, 29 kg, 26 joints, binocular depth camera, 6000 mAh battery for about 1 h; 12-month warranty.
Buying through Robotix Market
This unit is sourced new through established distribution channels and ships worldwide with the manufacturer warranty. Technical support is coordinated with the manufacturer's own service network. Deployment scope, configuration, and commissioning responsibilities are agreed as part of the quotation — on-site installation is not included in the product price.
Official Product Videos
Features
Specs
| Brand | Unitree Robotics |
|---|---|
| Model | R1 EDU Standard (U1); Unitree name: R1 EDU |
| Robot type | Bipedal humanoid robot |
| Size, standing | 1230 × 357 × 190 mm (height × width × thickness) |
| Size, folded | 690 × 450 × 300 mm |
| Weight | About 29 kg with battery |
| Colours | White or red; creative stickers to change the look |
| Body joints | 26 joint motors: 6 per leg, 5 per arm, 2 in the waist, 2 in the head |
| Total degrees of freedom | 26 |
| Leg and arm length | Calf + thigh 600 mm; forearm + upper arm 420 mm |
| Range of motion | Knee −10° to +139°; hip yaw ±157°, pitch −168° to +146°, roll −60° to +100°; waist yaw ±150°, roll ±30°; head yaw ±115°, pitch ±36° |
| Arm payload | About 2 kg per arm, varies greatly with arm posture |
| Drive | Low-inertia, high-speed inner-rotor PMSM joint motors; crossed roller and ball bearings; dual + single encoders; hollow internal wiring; local air cooling |
| Dexterous hands | None; the backpack's dexterous-hand expansion module provides power, signal and camera connections |
| Camera | Binocular depth camera in the head, 146° × 124° field of view; RGB 1280 × 720 at 30 Hz, depth 544 × 448 at 10 Hz |
| Computing | 8-core high-performance CPU + 10 TOPS visual computing module |
| Computing backpack | NVIDIA Jetson Orin, 40 TOPS (development computing unit) |
| Audio | 4-microphone array; stereo speakers, 3 W × 2 |
| Voice and image AI | Voice and image interaction through a large multimodal model when online; wake phrase "Hello Robot" or press-to-talk |
| Status light | 256-colour RGB chest light showing the robot's state |
| Wireless | Wi-Fi 6, Bluetooth 5.2 |
| Top panel | XT30 power outputs 24 V / 3 A and 36 V / 5 A; RJ45 gigabit Ethernet; stand-up / lie-down button |
| Battery | Quick-release smart battery, 6000 mAh |
| Run time | About 1 h per battery (less with fast walking, load or uneven ground) |
| Charger | 100–240 V input; 38 V, 3 A, 114 W output; about 1.5 h per charge, battery charged outside the robot |
| Remote control | Hard emergency-stop button and soft stop (L2 + B); 780 mAh, about 5 h; more than 100 m in an open environment |
| Control and updates | Unitree Explore app (iOS, Android), remote control and voice; smart OTA upgrades |
| Built-in actions | Running mode (low or high speed); dance modes including Kung Fu, Jeet Kune Do and Twist; gestures such as handshake, wave and clap |
| Secondary development | unitree_sdk2 in C++ and Python on DDS; compatible with ROS 2 (Foxy, Humble); high-level and joint-level control |
| Simulation models | URDF, STEP and MuJoCo models of the R1 |
| Navigation | Optional LiDAR for Unitree's SLAM and navigation service (static, flat indoor spaces under 45 m) |
| Operating environment | 0–40 °C on flat ground; not waterproof, not dustproof |
| Warranty | 12 months |
| In the box | The robot in a hard transport case, a quick-release R1 smart battery, the charger and charging cable, a remote control with emergency stop, a stand set (base, support rod, bracket, quick-release clamp, wave washer and protective foam), a calibration steel shaft, body stickers and the user manual; as an R1 EDU, the computing backpack with its NVIDIA Jetson Orin module (40 TOPS), expansion rails, screws, the dexterous-hand expansion module and its leads. Full packing list confirmed with your quotation |
Industries
Product Brochure
Unitree Robotics R1 EDU Standard (U1) – Product Brochure
The Robotix Market brochure with every capability and the full technical specification — to save, print or forward.
Download Brochure (PDF)Frequently Asked Questions
The Unitree Robotics R1 EDU Standard (U1) is priced at £12,250 in your market. For volume or project orders, contact us for a business quote.
Against the R1 Basic it adds secondary development, the computing backpack, the dexterous-hand expansion module and a 12-month warranty (R1 Basic: 8 months). Against the R1 EDU Smart (U2) it has a 40 TOPS Jetson Orin module instead of 100 TOPS. Against Pro A, Pro B, Pro C and Pro D it has no dexterous hands and the smaller module. The body, camera, audio and battery are the same on every R1.
Unitree's unitree_sdk2 in C++ and Python, on DDS with publish / subscribe and request / response, compatible with ROS 2 (tested on Ubuntu 20.04 Foxy and 22.04 Humble). It gives high-level interfaces for locomotion, arm actions, audio and video and joint-level control in debug mode. Unitree provides URDF, STEP and MuJoCo models of the R1 and a SLAM and navigation service for the optional LiDAR. Develop on Ubuntu 20.04; macOS and Windows are not supported.
Unitree's R1 unboxing film shows the robot in a hard transport case, a quick-release R1 smart battery, the charger and charging cable, a remote control with emergency stop, a stand set (base, support rod, bracket, quick-release clamp, wave washer and protective foam), a calibration steel shaft, body stickers and the user manual. As an R1 EDU it adds the computing backpack with its NVIDIA Jetson Orin module (40 TOPS), expansion rails, screws, the dexterous-hand expansion module and its leads. Unitree publishes no written packing list per edition, so we confirm the full list for your configuration with your quotation.
The backpack carries the dexterous-hand expansion module, with power, signal and camera connections, and Unitree publishes fitting guides for R1 EDU hands, the Dex3-1 and the BrainCo Revo 2 among them. The four configurations that come with two hands, Pro A to Pro D, use the 100 TOPS backpack. Hands for a robot you already own are confirmed with your quotation.
Like every R1 EDU, the R1 EDU Standard (U1) carries Unitree's 12-month manufacturer warranty (the R1 Basic: 8 months). It is sourced new through established distribution channels and ships worldwide, and technical support is coordinated with the manufacturer's service network. Unitree's R1 developer guide covers the SDK, the computing backpack and fitting the hands.
